- Product name
- Lenovo ThinkPad X1 Carbon Gen 10 Laptop (14-Inch)
- Model Name
- Lenovo ThinkPad X1 Carbon Gen 10 Laptop (14-Inch)
- Display Type Options
- 14-in WQUXGA (3840 x 2400) IPS low power AOFT touch with Dolby Vision™ DCI P3 100%, 500 nits, Eyesafe® certified low blue-light emissions, antiglare, antireflective, antismudge
- 14-in WUXGA* (1920 x 1200) IPS, low power, PrivacyGuard touch, 500 nits, antiglare, TÜV ePrivacy certified
- Processor & Graphic Options
- Intel® Core™ i5-1240P Processor (1.7GHz Max Turbo Frequency Up to 4.4GHz) 12 MB Intel® Smart Cache, 12-Cores, 16 Threads | Intel Iris Xe Graphics
- Operating System
- Windows OS
- #1
- Intel® Core™ i5-1235U Processor (0.9GHz / 1.3GHz to 3.3GHz / 4.4GHz Max Frequency Turbo Up) 12 MB Intel® Smart Cache, 10-Cores ( 2 P-Cores + 8 E-Cores), 12-Threads | Intel Iris Xe Graphics
- #2
- Intel® Core™ i5-1240P Processor (1.2GHz / 1.7GHz Up to 3.3GHz / 4.4GHz Max Turbo Frequency) 12 MB Intel® Smart Cache, 12-Cores (4 P-Cores + 8 E-Cores), 16 Threads | Intel Iris Xe Graphics
- #3
- Intel® Core™ i5-1245U Processor (1.2GHz / 1.6GHz Up to 3.3GHz / 4.4GHz Max Turbo Frequency) 12 MB Intel® Smart Cache, 10-Cores ( 2 P-Cores + 8 E-Cores), 12 Threads | Intel Iris Xe Graphics
- #4
- Intel® Core™ i5-1250P Processor (1.2GHz / 1.7GHz Up to 3.3GHz / 4.4GHz Max Frequency Turbo) 12 MB Intel® Smart Cache, 12-Cores (4 P-Cores + 8 E-Cores), 16-Threads | Intel® Iris® Xe Graphics eligible
- #5
- Intel® Core™ i7-1255U Processor (1.2GHz / 1.7GHz up to 3.5GHz / 4.7GHz Max Turbo Frequency), 12 MB Intel® Smart Cache, 10-Cores ( 2 P-Cores + 8 E-Cores), 12 Threads | 12 MB Intel® Smart Cache
- #6
- Intel® Core™ i7-1260P Processor (1.5GHz / 2.1GHz up to 3.4GHz / 4.7GHz Max Turbo Frequency) 18 MB Intel® Smart Cache, 12-Cores (4 P-Cores + 8 E-Cores), 16 Threads | Intel® Iris® Xe Graphics eligible
- #7
- Intel® Core™ i7-1265U Processor (1.3GHz / 1.8GHz Up to 3.6GHz / 4.8GHz Max Turbo Frequency) 10 MB Intel® Smart Cache, 10-Cores ( 2 P-Cores + 8 E-Cores), 12 Threads | Intel Iris Xe Graphics
- Intel® Core™ i5-1250P Processor (1.7GHz Max Frequency Turbo Up to 4.4GHz) 12MB L3 Cache, 12-Cores 16-Threads | Intel® Iris® Xe Graphics eligible
- #8
- Intel® Core™ i7-1270P Processor (1.6GHz / 2.2GHz Up to 3.5GHz / 4.8GHz Max Turbo Frequency) 18 MB Intel® Smart Cache, 12-Cores (4 P-Cores + 8 E-Cores), 16 Threads | Intel Iris Xe Graphics
- #9
- Intel® Core™ i7-1280P Processor (1.3GHz / 1.8GHz Up to 3.6GHz / 4.8GHz Max Turbo Frequency) 24 MB Intel® Smart Cache, 14 Cores (6 P-Cores + 8 E-Cores), 20 Threads | Intel® Iris® Xe Graphics
- Chipset
- Intel® SoC (System on Chip) platform
- Memory
- 8GB RAM / 16GB RAM / 32GB RAM
- Audio
- 1 x 1/8-in / 3.5 mm Headphone/Microphone Input/Output | Built-In Speakers
- Storage
- 256GB SSD / 512GB SSD / 1 TB SSD / 2TB SSD / 4TB SSD
- Camera
- Full HD Webcam with Privacy Shutter | Webcam User-Facing
- Monitor Support
- Supports up to 4 independent displays (native display and 3 external monitors via Thunderbolt™ and HDMI®) / Thunderbolt™ supports up to 5K@60Hz / HDMI® supports up to 4K@60Hz
- Wireless
- Wi-Fi:- Wi-Fi 6E (802.11ax) | MU-MIMO Support
- Card Reader
- No card reader
- Ports and Connectors
- 2 x USB Type-A (USB 3.1 / USB 3.2 Gen 1) | USB Type-C
- Audio Chip
- High Definition (HD) Audio, Realtek® ALC3306 codec
- Speakers
- Stereo speakers, 2W x2 woofers and 0.8W x2 tweeters, Dolby Atmos®
- Microphone
- Quad-microphone array, 360° far-field, Dolby Voice®
- Camera OPTIONS
- FHD 1080p + IR discrete, with privacy shutter, MIPI, fixed focus, Computer Vision / FHD 1080p + IR hybrid, with privacy shutter, fixed focus / FHD 1080p, with privacy shutter, fixed focus / HD 720p, with privacy shutter, fixed focus
- Battery
- Integrated Li-Polymer 57Wh battery, supports Rapid Charge (charge up to 80% in 1hr) with 65W AC adapter
- Power Adapter OPTIONS
- 45W USB-C® (2-pin) AC adapter, supports PD 3.0, 100-240V, 50-60Hz // 45W USB-C® (3-pin) AC adapter, supports PD 3.0, 100-240V, 50-60Hz // 65W USB-C® (2-pin) AC adapter, supports PD 3.0, 100-240V, 50-60Hz // 65W USB-C® (3-pin) AC adapter, supports PD 3.0, 100-240V, 50-60Hz // 65W USB-C® slim (2-pin) AC adapter, supports PD 3.0, 100-240V, 50-60Hz // 65W USB-C® slim (3-pin) AC adapter, supports PD 3.0, 100-240V, 50-60Hz // No power adapter
- Keyboard
- 6-row, spill-resistant, air intake design, multimedia Fn keys with Unified Communications controls
- Keyboard Backlight
- LED backlight
- UltraNav™
- TrackPoint® pointing device and glass surface multi-touch touchpad, 56 x 110 mm (2.20 x 4.33 inches)
- Ethernet
- No onboard Ethernet
- WLAN + Bluetooth® OPTIONS
- Intel® Wi-Fi® 6 AX201, 802.11ax 2x2 Wi-Fi® + Bluetooth® 5.1 (Bluetooth® 5.2 hardware ready) // Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 Wi-Fi® + Bluetooth® 5.1 (Bluetooth® 5.2 hardware ready)
- WWAN OPTIONS
- Wireless WAN upgradable to 4G (with antenna ready) // Fibocom L860-GL-16, 4G LTE CAT16, MIMO 4x4, M.2 card // Fibocom FM350-GL, 5G Sub-6 GHz, M.2 Card, with embedded eSIM functionality // No support
- SIM Card OPTIONS
- Gemalto eSIM card (physical) // No physical SIM card inbox
- NFC OPTIONS
- Near Field Communication // No support
- Standard Ports
- 1x USB 3.2 Gen 1 | 1x USB 3.2 Gen 1 (Always On) | 2x Thunderbolt™ 4 / USB4® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4a) | 1x HDMI® 2.1, up to 4K/60Hz | 1x Headphone / microphone combo jack (3.5mm)
- Docking
- Various docking solutions supported via Thunderbolt™ / USB-C®.
- Security Chip
- Discrete TPM 2.0, TCG certified, FIPS 140-2 certified
- Physical Locks
- Kensington® Nano Security Slot™, 2.5 x 6 mm
- Smart Card Reader
- No smart card reader
- Fingerprint Reader
- Touch style fingerprint reader integrated in power button, match-on-chip
- BIOS Security
- Supervisor password | Power-on password | System management password | NVMe® password | Certificate based BIOS authentication | FIDO (Fast Identity Online) authentication | Self-healing BIOS
- Other Security
- Privacy Guard with Privacy Alert (models with ThinkPad® Privacy Guard display) | (Optional) IR camera for Windows® Hello (facial recognition) | Camera privacy shutter | Glance by Mirametrix® | (Optional) Computer Vision-based User Presence Sensing including lock on leave | Tile ready
- Green Certifications
- ENERGY STAR® 8.0 | | EPEAT™ Gold Registered | ErP Lot 3 | RoHS compliant | TCO Certified 9.0
- Mil-Spec Test
- MIL-STD-810H military test passed
- Other Certifications
- (Optional) Intel® Evo™ Platform | (Optional) Eyesafe® Certified | (Optional) TÜV Rheinland® Low Blue Light (Hardware Solution) | TÜV Rheinland® Dynamic Privacy Filter (DPF) Certification (Privacy Guard models)
- Dimensions
- (Models with 720p camera) - 315.6 x 222.5 x 14.95 mm (12.43 x 8.76 x 0.59 inches) // (Models with other camera) - 315.6 x 222.5 x 15.36 mm (12.43 x 8.76 x 0.60 inches)
- Weight
- Starting at 1.12 kg (2.48 lbs)
